13
Cordless Lawn mower EN
2. Motor stops
while mowing.
A. Release Operating Bail to turn
mower off. Remove safety key and
batteries,turn mower over and check
that blade is free to turn. If not free,
return to an authorized servicer.
Blade should turn freely.
B. Raise cutting height of wheels to
highest position and start mower.
C. Has battery been fully charged?
Plug in charger and wait for green
light to come on.
D. Avoid overloading the mower. Slow
down the cutting pace by pushing
mower slower or raise the cut height.
Or both.
3. Mower runs
but cutting
performance is
unsatisfactory,
or does not cut
entire lawn.
A. Has battery been fully charged? Plug
in charger and wait for green light to
come on.”
B. Release Operating Bail to turn mower
off. Remove safety key and batteries.
Turn mower over and check: Blade for
sharpness - Keep blade sharp. Deck and
discharge chute for clogging.
C. Wheel height adjustment may be set
too low for grass condition. Raise cutting
height.
4. Mower is too
hard to push.
A. Raise cutting height to reduce
deck drag on grass. Check each
wheel for free rotation.
5. Mower is
abnormally
noisy and
vibrates.
A. Release Operating Bail to turn
mower off. Remove safety key
and batteries. Turn mower on
side and check blade to ensure it
has not been bent or damaged. If
blade is damaged, replace with a
replacement blade. If the underside
of the deck is damaged return mower
to an Authorized service center.
B. If there is no visible damage to the
blade and the mower still vibrates:
Release Operating Bail to turn mower
off, Remove safety key and batteries,
and remove blade. Rotate blade 180
degrees and retighten. If mower
still vibrates, return the mower to an
authorized service center.
6. Battery
charger LED’s
not on.
A. Check plug connection.
B. Replace charger.
7. Battery
charger LED
does not flip to
green.
A. Battery needs to be diagnosed.
Take to authorized service center.
8. Mower not
picking up
clippings with
the Grass
Collection Bag.
A. Remove mulch plate when
bagging.
B. Chute clogged. Release Operating
Bail to turn mower off. Remove safety
key and batteries. Clear chute of
grass clippings.
C. Too much cut grass. Raise cutting
height of wheels to shorten length
of the cut.
D. Bag full. Empty bag more often.
9. When
mulching there
are clippings
visible.
A. Too much cut grass. Raise cutting
height of wheels to shorten length of
the cut. Do not cut off more than 1/3
of total length.
B. Check blade for sharpness. Always
keep blade sharp.
10. Low or
diminished run-
time after many
uses
A. Return to Authorized Service
location - may need new battery.
11. The battery
charger LED
flashes red and
the battery can’t
be charged.
A. The battery overheats after
continuous use. Remove battery
from the charger and allow it to cool
to 42°C or less.
ENVIRONMENTAL
PROTECTION
Disposal
The machine, its accessories and packaging
materials should be sorted for environmentally friendly
recycling. The plastic components are labeled for
categorized recycling.
