Cordless Lawn mower EN

9. BATTERY PACK COVER

10. REAR HANDLE

11. SAFETY FLAP

12. SAFETY LOCKOUT BUTTON

13. QUICKRELEASE BUTTON

14. MULCHING INSERT

15. BATTERY PACK SEE FIG. C2

16. SAFETY KEY SEE FIG. F2

17. POWER INDICATOR LIGHTSEE FIG. H

18. BLADE BOLT SEE FIG. O1

19. BLADE SEE FIG.O1

20. SPACER SEE FIG. O1

*Not all the accessories illustrated or described are

included in standard delivery.

TECHNICAL DATA

Type WG749E WG749E.9(7-

designation of ma-

chinery, representative of Cordless Lawn Mower)

WG749E WG749E .9

Voltage 40V Max.(2x20V Max.)**

No load speed 2800/min

Deck width 48 cm

Cutting width 46 cm

Front wheel diameter

200 mm

Rear wheel diameter

230 mm

Cutting height 20 – 80 mm

Cutting height positions

Grass collection capacity

55 L

Battery capacity 4.0 Ah (WA3014) /

Battery type Lithium-Ion /

Charger Model WA3883 /

Charger rating Input: AC 100-

240V~50/60 Hz

Output 1: 20 V ,

2.0 A***

Output 2: 20 V ,

2.0 A***

Charging time

(approx.)

4.0 Ah (1 pc)

4.0 Ah (2 pcs)

1 hr

2 hrs

Machine Weight 28.7 kg 27.3 kg

** Voltage measured without workload. Initial battery

voltage reaches maximum of 20 volts. Nominal voltage is

18 volts.

*** Charger output 1 and output 2 mean two ports with the

same output voltage and current.

ACCESSORIES

WG749E WG749E .9

Battery pack (WA3014) 2 /

Charger (WA3883) 1 /

Grass collection bag 1

Mulching insert 1

We recommend that you purchase your accessories from

the same store that sold you the tool. Choose the type

according to the work you intend to undertake. Refer

to the accessory packaging for further details. Store

personnel can assist you and offer advice.

NOISE DATA

A weighted sound pressure L

= 78.4 dB(A)

3.0 dB (A)

A weighted sound power L

= 91.6 dB(A)

3.0 dB (A)

Wear ear protection
