6 Mirka® DEROS • 77 mm (3"), 125 mm (5") & 150 mm (6") • 230 V Mirka® DEROS • 77 mm (3"), 125 mm (5") & 150 mm (6") • 230 V 7

Parts list – DEROS 77 mm spareparts & accessories

Mirka code Item Description Kit Quantity

Tightening

torque

MIE6210111 1 Lever 2.5 mm (77 mm & 150 mm) 1

MIE6510111 1 Lever 5.0 mm (77 mm, 125 & 150 mm) 1

2 Start button A 1

3 Start button spring A 1

MIE6510411 4 Cover plate 1

5 Screws B 4

MIE6510611 6 Speed controller * 1

MIE9016011 7 Rewireable mains cable 4.3 m CE 230 V EU 1

MIE9017011 7 Rewireable mains cable 4.3 m CE 230 V UK 1

MIE9017111 7 Rewireable mains cable 4.3 m CE 230 V CH 1

MIE9017511 7 Rewireable mains cable 4.3 m CE 230 V ANZ 1

MIE6517411 7 Mains cable 4.3 m CE 230 V CN 1

MIE3520811 8 Housing 1

9 Housing screws B, C 2,2

10 Swivel exhaust C 1

MIE3221111 11 Motor 2.5 mm / 30 g pad (77 mm) 1 25 Nm

MIE3521111 11 Motor 5.0 mm / 30 g pad (77 mm) 1 25 Nm

MIE3511211 12 Fan 5.0 mm / 30 g pad (77 mm) 1

13 Retaining ring D 1

14 Bearing D 1

15 Spacer D 1

16 Bearing with dust seal D 1

17 Shim D 1

18 Belleville washer D 1

19 Retaining ring, 22.2 mm D 1

8993015011 20 Spindle 1/4" 77 mm 1

8993008013 21 Pad wrench 17 mm 1

MIE3512211 22 Brake seal 1

8294791211 23 Backing pad 77 mm 1/4" Grip 6H Medium 1

25 Type label DEROS 325 E 1

25 Type label DEROS 350 E 1

35 Screws B 1

* Spare parts only available to authorized repairers.
