8 Mirka® DEROS • 77 mm (3"), 125 mm (5") & 150 mm (6") • 230 V

Parts list – DEROS 125/150 mm kits

Mirka code Item Description Kit Quantity

Tightening

torque

MIE6520211 Start button kit A

2 Start button 1

3 Start button spring 1

MIE6520511 Screw kit B

5 Screws 4 0.6 Nm

9 Housing screws 2 1.4 Nm

35 Screws 2 0.6 Nm

MIE6521011 Swivel exhaust kit C

9 Housing screws 2 1.4 Nm

10 Swivel exhaust 1

MIE6536211 Bearing dual seal kit D

13 Double row bearing 1

14 Dual seal 1

15 Washer 1

16 Retaining ring 1

MIE6536011 Spindle bearing dual seal kit E

13 Double row bearing 1

14 Dual seal 1

15 Washer 1

16 Retaining ring 1

17 Spindle 5/16" 1

8995690101 Balancing screw kit F

21 Screws 5

22 Nut 3

Hex key 1

MIE6522511 25 Type label kit EU (550, 625, 650, 680) G 40

MIE6522511CN 25 Type label kit CN (625, 650) G 20

MIE6522511AN 25 Type label kit ANZ (650, 680) G 20

NOTE! Repairs done by non-authorized repairer will breach the Mirka warranty.

Electrical tool must be serviced by a qualied repair person and in accordance with national requirements.
