8 Mirka® DEROS • 77 mm (3"), 125 mm (5") & 150 mm (6") • 230 V Mirka® DEROS • 77 mm (3"), 125 mm (5") & 150 mm (6") • 230 V 9

Parts list – DEROS 125/150 mm spareparts & accessories

Mirka code Item Description Kit Quantity

Tightening

torque

MIE6210111 1 Lever 2.5 mm (77 & 150 mm) 1

MIE6510111 1 Lever 5.0 mm (77, 125 & 150 mm) 1

MIE6810111 1 Lever 8.0 mm (150 mm) 1

2 Start button A 1

3 Start button spring A 1

MIE6510411 4 Cover plate 1

5 Screws B 4

MIE6510611 6 Speed controller * 1

MIE9016011 7 Rewireable mains cable 4.3 m CE 230 V EU 1

MIE9017011 7 Rewireable mains cable 4.3 m CE 230 V UK 1

MIE9017111 7 Rewireable mains cable 4.3 m CE 230 V CH 1

MIE9017511 7 Rewireable mains cable 4.3 m CE 230 V ANZ 1

MIE6517411 7 Mains cable 4.3 m CE 230 V CN 1

MIE6520811 8 Housing 1

9 Housing screws B, C 2, 2

10 Swivel exhaust C 1

MIE5521111 11 Motor 5.0 mm / 100 g pad (125 mm) * 1 25 Nm

MIE6221111 11 Motor 2.5 mm / 130 g pad (150 mm) * 1 25 Nm

MIE6521111 11 Motor 5.0 mm / 130 g pad (150 mm) * 1 25 Nm

MIE6821111 11 Motor 8.0 mm / 130 g pad (150 mm) * 1 25 Nm

MIE65111B1 11-B Ground wire 1

MIE5511211 12 Fan 5.0 mm / 100 g pad (125 mm) 1

MIE6211211 12 Fan 2.5 mm / 130 g pad (150 mm) 1

MIE6511211 12 Fan 5.0 mm / 130 g pad (150 mm) 1

MIE6811211 12 Fan 8.0 mm / 130 g pad (150 mm) 1

13 Double row bearing D, E 1

14 Dual seal D, E 1

15 Washer D, E 1

16 Retaining ring D, E 1

8995603201 17 Spindle 5/16" E 1

8995604121 18 Pad wrench 24 mm for 125/150 mm 1

8995603211 19 Brake seal 1

8292502011 20 Backing pad Net 125 mm 5" 5/16" 28H Medium 100 g 1

8292502511 20 Backing pad Net 125 mm 5" 5/16" 28H Medium 130 g 1

8292605011 20 Backing pad Net 150 mm 6" 5/16" 48H Medium 130 g 1

21 Screws F 5

22 Nut F 3

25 Type label EU G 1

25 Type label CN G 1

25 Type label ANZ G 1

35 Screws B 2

* Spare parts only available to authorized repairers.
