ENGLISHen

Keep other people away.

Maintain a distance of at

least 15 m from persons

and objects.

Protect the device from water and moisture.

Do not expose to rain.

Wear safety goggles.

Wear ear protectors. High noise levels over a

prolonged period of time may affect your

hearing.

Wear head protection if there is the risk of

falling parts.

Wear non-slip foot protection.

Do not use metal blades and metal saw

blades.

Wear gloves.

See pages 2 and 3.

1 Rod (two-piece)

2Handle

3 Suspension point

4Handle

5Switch lock

6 Switch (switching on/off, setting speed)

7 Battery pack release button

8 Capacity indicator button *

9Battery pack *

10 Capacity and signal indicator *

11 Arrows show the direction of line head

12 Line cutter (WARNING! Danger of injury from

the sharp edges of the blade)

13 Safety guard

14 Line head

15 Plant guard

16 Thread (cutting line)

17 Cap (of the line head)

18 Base body (of the line head)

19 Unlock button

20 Wing nut

21 Screwdriver

22 Screws (to fix the safety guard)

23 Flange (guard)

24 Drive shaft

25 Drilled hole (to lock the drive shaft)

26 Allen key

27 Screws of the handle

28 Holes (to fix the plant guard)

29 Shoulder strap

30 Carabiner hook

*equipment-specific

WARNING! Switch off the machine and

remove (9) battery pack. Unintentional startup

can cause serious injuries. The machine must be

stationary.

WARNING! Danger of injury from sharp

cutting edge on the line cutter (12). Wear

protective gloves.

6.1 Assembling/disassembling rod (1) (fig.

Assembling:

1. Push the rod ends into each other so that the

release button (19) engages.

2. Tighten the wing screw (20).

Disassembling (for transport / storage):

1. Release the wing (20) screw.

2. Press the release button (19) and pull apart the

rod ends at the same time.

6.2 Attaching the guard (13) (fig. C)

WARNING! Danger of injury from sharp

cutting edge on the line cutter (12). Wear

protective gloves.

1. Place the safety guard (13) onto the flange (23).

2. Insert the screws (22) with screwdriver (21) and

firmly tighten them.

6.3 Attaching / removing the line head (14)

(fig. D)

Fitting

1. Locking the drive shaft (24):

- Insert the supplied Allen key (26) into the drilled

hole (25).

- Turn the drive shaft (24) by hand until the Allen

key (26) can be pushed in and the drive shaft

cannot be turned anymore.

2. As shown, screw on the line head (14) in anti-

clockwise direction and tighten by hand.

3. Release the drive shaft:

- Pull out the Allen key (26).

Removal

Proceed in the same way as for the attachment,

however unscrew the line head in clockwise

direction.

6.4 Insert cutting line (16) in line head (14)

(fig. A)

1. Hold tight the base body (18). Turn the cap (17)

in clockwise direction until the triangular marks

are opposite each other (and/or the continuous

groove on the side of the print head is aligned

with the triangle of the line head’s cap).

2. Bend the end of the line straight (so that it can be

inserted more easily).

Push the line end (16) into the opening marked

with an arrow and the words “LINE IN. NOTE:

See fig. A: Push in exactly in the direction of the

arrow (slightly slanted)!

5. Overview

6. Initial Operation
