INSTALLATION

1. PRODUCT MOUNTING See “General Warnings” N°.1 to N°.6

For product installation, refer to drawings section 1 page.2 and page 3.

2. HYDRAULIC CONNECTION See “General Warnings” N°.10 to N°.14

For hydraulic connection, refer to drawings section 2 page 4.

- It is necessary to clean the supply piping prior to the hydraulic connection. The connection to the hot water

outlet is to be carried out with a cast iron or steel sleeve or a dielectric connector, to avoid corrosion of the

pipe (direct contact iron / copper). The use of brass fittings is prohibited.

- Always install a new safety device on the cold water pipe of the water heater, which comply with the

standards (EN 1487 in Europe), with a pressure of 7 or 9 bars (0.7 or 0.9 MPa) according to the nominal

pressure, with diameter 1/2".

- Do not use the safety valve included in this packaging in France (home country and French

overseas)

3. ELECTRICAL CONNECTION

For electrical connection, refer to drawings section 3 page 4.

- The water heater can be connected and operated only on AC 230V. Connect the heater with a rigid cable

with conductors 2,5mm ². Use a standardised channeling (rigid or flexible conduit) until the calibrated

housing cover.

- Directly connect devices with a cable or plug. In France, a product with plug is strictly prohibited and cannot

be sold and installed.

- Always connect the earth conductor of the cable to the earth ground wire or connect the earth conductor to

the appropriate terminal identified by the symbol . This connection is compulsory for safety reasons. The

earth wire green - yellow must be longer than those of phases. The installation must be equipped, upstream

of the appliance, with a bipolar cut-out device (minimum contact distance of 3 mm fuse, breaker switch). In

the case where hydraulic connexions are in insulated material, electrical circuits shall be protected by a

differential circuit breaker 30 mA adapted to local standards.

Thermal circuit breaker (see drawings section 5 page 4): All our products are equipped with a thermostat

with thermal circuit breaker and manual resetting which cuts off the power supply to the water heater in case of

overheating. If the safety trips:

 switch off the power before taking any further action,

 remove the cover,

 check the electrical connections,

 reset the thermal circuit breaker

If the circuit breaker keeps tripping, replace the thermostat. Never short circuit the safety cut out or the

thermostat. Connect the power supply only via the terminal.
