6 English 2207110

*2207110*

3.6 Selection of the connecting material

A table to assist with selecting the type of cable and cable terminal to be used can be found at the end of

these operating instructions.

4 Technical data

NCR 060 II-A22

Rated voltage

21.6 V

Weight in accordance with EPTA Procedure 01 including batteryB22⁄8.0

3.3 kg

Max. crimping force

53 kN

Crimping time

≈ 5 s

Max. permissible crimping capacity

• 500 MCM (240

mm²) Cu

• 350 MCM

(240 mm²) Al

Storage temperature

−20 ℃ … 70 ℃

Ambient temperature for operation

−17 ℃ … 60 ℃

4.1 Noise information and vibration values in accordance with EN 60745

The sound pressure and vibration values given in these instructions were measured in accordance with a

standardized test and can be used to compare one power tool with another. They can also be used for a

preliminary assessment of exposure. The data given represents the main applications of the power tool.

However, if the power tool is used for different applications, with different accessory tools, or is poorly

maintained, the data can vary. This can significantly increase exposure over the total working period. An

accurate estimation of exposure should also take into account the times when the tool is switched off, or

when it is running but not actually being used for a job. This can significantly reduce exposure over the

total working period. Identify additional safety measures to protect the operator from the effects of noise

and/or vibration, for example: Maintaining the power tool and accessory tools, keeping the hands warm,

organization of work patterns.

Noise values

Sound (power) level (L

)

80 dB(A)

Uncertainty for the sound power level (K

)

2.5 dB(A)

Emission sound pressure level (L

)

70 dB(A)

Uncertainty for the sound pressure level (K

)

2.5 dB(A)

Vibration values

Total vibration (during operation) (a)

2.5 m/s²

Uncertainty (K)

1.5 m/s²

4.2 Battery

Battery operating voltage

21.6 V

Ambient temperature for operation

−17 ℃ … 60 ℃

Storage temperature

−20 ℃ … 40 ℃

Battery charging starting temperature

−10 ℃ … 45 ℃
