5
.COM
Socket 775
Socket 1156/1155
Socket 1366
Take note of the orientation of the Nuts and the Side Caps.
X
O
Caution
2) Intel Socket LGA 1366/1156/1155/775 Installation
①
Insert the Nuts to the Backplate according to the socket type
and secure them with Side Caps.
1
2
②
Socket LGA 1366/1156/1155 Installation
Peel off one side of the Double-sided Tape and attach it to the center of the
Backplate with the sticky side facing down. Then, peel off the top cover.
※
Socket LGA 1366/1156/1155 Installation does not require the Loading Block.
