Zalman CNPS9900 NT [10/11] Caution
![Zalman CNPS9900 NT [10/11] Caution](/views2/1110976/page10/bga.png)
9
.COM
③
Peel off the Loading Block cover and attach it to the Backplate with the
sticky side facing the center of the Backplate.
Caution
Please note that the sticky side of the Loading Block serves to attach the Loading Block to
the backplate.
Peel off one side of the Double-sided Tape and attach it with the sticky
side facing the Loading block. Then, peel off the top cover.
Loading Block
Double-sided Tape
O
X
④
Dismantle the CPU cooler retention bracket on the motherboard by unscrewing the
four bolts located at each corner (method may vary; consult the motherboard manual for
details). Be sure to keep the retention bracket so the stock CPU cooler can be used as a
backup.
M/B
M/B
