8
.COM
1) AMD Socket FM2/ FM1/AM3+/AM3/AM2+/AM2 Installation
①
Partially unscrew the four bolts located on the base of the CPU cooler.
Then, insert the AMD Clips between the base and the heatpipe cover,
with the clips bent away from the heatsink.
B. AMD Socket Installation
②
Insert the Nuts to the Backplate according to the socket type and secure
them with Side Caps.
1
2
X
O
Take note of the orientation of the Nuts and the Side Caps.
Caution
The holes in the Clip (as shown
below) are matched to the “keys” on
the heatpipe cover for secure Clip
installation.
Insert
Key
AMD Clip
Base
Heatpipe cover
