442981_b 25

Storage

3. Remove the counterplate and guide plate

(12/1) by loosening the three M8 nuts (12/4).

4. Loosen and remove countersunk head

screws M8x10 (12/2).

5. Remove and turn blade (12/3). Replace the

blades if both sides are blunt.

6. Secure blade (12/3) using the countersunk

head screws M8x10 (12/2) and turn or re-

place the second blade.

7. Then fit the counterplate and guide plate

(12/1) again and tighten the M8 nuts (12/4).

8. Finally fit and screw the shredder upper sec-

tion tight.

8.3 Re-adjusting the counterplate (LH 2810)

(07)

A worn or damaged cutting drum and counter-

plate may only be replaced by an authorised spe-

cialist.

To obtain an optimum shredding result and pre-

vent damage to the blade unit (07/3), the counter-

plate (07/2) must be readjusted at regular inter-

vals.

The counterplate must also be adjusted if materi-

al frequently becomes jammed between counter-

plate and blade.

With the motor running:

1. Turn adjusting screw (07/1) 1/6 turn to the

right (clockwise), until a slight grinding noise

can be heard and fine aluminium chips fall

from the ejector chute for a short period of

time.

2. The material to be shredded should now be

cut completely again.

8.4 Care

■

Remove dirt and material residues after ev-

ery use.

■

Do not clean the machine with running water

or high-pressure.

■

Do not use any cleaning agents or solvents.

■

Use a soft brush or cloth for cleaning.

■

To protect the inner side of the housing from

corrosion, spray it with a biologically degrad-

able oil.

9 STORAGE

Clean the shredder after its use. Store it in a dry,

lockable place out of the reach of children.

Perform the following tasks when storing during

the winter period:

MH2810 (11/12)

1. Switch off the machine and disconnect it from

the mains power supply.

2. Wait for the cutting disk to come to a stand-

still.

3. Loosen locking screw (11/1) and remove

shredder upper section (11/2).

4. Remove coarse and wet material to be

shredded from the inside of the shredder.

5. Spray the shredder blades (12/3) with an oily

care spray.

6. Empty the collector box.

7. Finally fit and screw the shredder upper sec-

tion (11/2) tight again.

8. Store the shredder upright.

LH2810

1. Switch off the machine and disconnect it from

the mains power supply.

2. Empty the collector box.

3. Store the shredder upright.

10 HELP IN CASE OF MALFUNCTIONS

NOTE For malfunctions that are not listed

in this table or that you cannot resolve yourself,

please contact our customer service.

MH 2810

Malfunction Possible cause Solution

Motor does not start. Collector box missing or not

locked.

Push collector box in completely and

lock it.

Mains socket (house installation)

defective.

Use a different mains socket in the

house.

Extension lead defective. Inspect the lead and replace it, if

necessary.
