Zalman MS800 Plus [14/65] 7 3 hdd tray installation
![Zalman MS800 Plus [14/65] 7 3 hdd tray installation](/views2/1111191/page14/bge.png)
12
MS800 Series
(7) 3.5" HDD Tray Installation
B Bolt
Remove the HDD tray after removing the HDD Cover as shown.
1. To install 3.5"HDD pull the tray sideways as shown.
3.5"HDD Installation
2.5"HDD/SSD Installation
˝
5SBZ3FNPWBM
˞
Attach 3.5"/2.5" HDD to Tray
HDD
