![Zalman MS800 Plus [9/65] 4 expolded view ms800 plus](/img/pdf.png)
Zalman MS800 Plus [9/65] 4 expolded view ms800 plus
![Zalman MS800 Plus [9/65] 4 expolded view ms800 plus](/views2/1111191/page9/bg9.png)
7
ENG
MS800 Series
# Part Name Units
˝
Chassis 1
˞
Top Cover 1
˟
Side Panel (Right) 1
ˠ
Side Panel (Left) 1
ˡ
Fan Filter 1
ˢ
Bottom Cover 1
# Part Name Units
ˣ
3.5”/2.5” to 5.25"Tray
6XSSRUW+RWVZDS[
4
ˤ
Front I/O Panel 1
˥
Front Cover 1
˦
5.25” Bay Covers 10
˧
VGA Guide 1
˨
HDD Module 1 set
(4) Expolded View (MS800 Plus)
˨
*Acrylic Side Panel is only available on the MS800 Plus.
˝
˞
˟
ˠ
ˡ
ˢ
ˣ
˦
˧
ˤ
˥
