11. Menu Description

■ To use Virtual ODD, iso le must be located in the “_iso” folder of device.

■ Enter into or free from menu if Jog switch is pressed for 3seconds.

■ If backup button is pressed on Menu, it moves to 1 upper layer.

- Except Menu, Backup button is used for its original function, Data Backup.

■ External HDD or CD-ROM may not be recognized according to current mode states.

(1) Main Menu

Mode Select > Device Mode setting

Setting > Setting LCD brightness or Sleep Mode time

Information > Check HDD information and rmware information

USB Connect > Setting USB connection

Advanced > Setting Virtual HDD mounting

Exit Menu Exit

(2) Mode Select (“ν”is shown in selected mode)

Dual Mode Both of external HDD and CD-ROM are recognized

ODD Mode ExternalCD-ROM is recognized. (Useful when OS installing)

HDD Mode External HDD is recognized.

(Useful when connecting other devices except PC)

(3) Setting

LCD Bright > AdjustLCD backlight brightness

Idle Bright > Adjust LCD backlight brightness in Sleep Mode

Standby time > Sleep Mode time setting

Load Default Return to default value

(4) Information

S.M.A.R.T > Hard disk SMART information

HDD Model > Display Hard disk model name

HDD Serial > Display Hard disk serial number

Firmware Ver. > Display device rmware version

USB Speed > Display current PC connection

(USB2.0: Hi-speed, USB3.0: Super-speed)

USB Input Volt > Display the lowest Power Current (V) from USB port after

connecting with PC

Display current Power Current (V)

(5) S.M.A.R.T

HDD Temp. > Display HDD temperature

HDD Health > Display HDD health info (Good, Warning, Bad)

- If Warning or Bad is shown, please check HDD carefully after

backup date.
