4-3. Do-it-yourself maintenance

AYGO_WE_99E96E

: Vehicles without VSC system

: Vehicles with VSC system

: Replace the fuse with one of the same ampere rating as the original

10 AM2 30 A

Starting system, IG1, IG2, STA

fuses

11 HAZARD 10 A

Turn signal lights, emergency

flashers, gauges and meters

12 H-LP MAIN 20 A H-LP LH, H-LP RH fuses

13 DOME 15 A

Gauges and meters, interior light,

audio system, tachometer

14 EFI 15 A

Electric cooling fan, multiport fuel

injection system/sequential multi-

port fuel injection system

15 HORN 10 A Horn

16 SPARE 7.5 A Spare fuse

17 SPARE 10 A Spare fuse

18 SPARE 15 A Spare fuse

19 AMT 50 A Multi-mode manual transmission

20 RADIATOR

30 A

Electric cooling fan

40 A

ABS

40 A

Anti-lock brake system

VSC*

50 A

Anti-lock brake system and vehicle

stability control system

22 EMPS 50 A Electric power steering system

Fuse Ampere Circuit
