4.InstallationRequirements

4) Cooler Orientation

3) Protective Brace Removal

Please unclip and remove the heatsink’s Plastic Brace before installing the cooler.

The Plastic Brace is in place to protect the cooler during transport.

Inrelationtothecooler’scentrallylocatedfan,airowsfromthe“thinner”(front)heatsink

tothe“thicker”(rear)heatsink.Asshowninthediagrambelow,itisrecommendedthat

thecoolerbeinstalledsothatairowsfromthecoolertowardtheenclosure’srear

exhaust fan to be released.

96㎜

154㎜

133㎜

PSU

VGA slot

Front SideRear Side

Enclosure’s (Rear) Exhaust

1)SpaceRequirements

2) Air Guide Removal

Thecooler’sinstallationrequiresunobstructedspacewithdimensionsof

133mm(width), 154mm(length), 96mm(height), and the CPU as a central

reference point. Please check if components such as ODDs and PSU protrude

intotherequiredspace.

Air guides on enclosures must be removed, before the cooler’s installation, for

theyprotrudeintothecooler’srequiredspace.
