Warning
• Avoid to touch woofer cone or to remove tweeter dome grille.
• Make sure that wire and fast-on connectors don’t cause short circuits with the car
metallic parts.
• In order to avoid possible damages, keep all components in their package until you
install them.
• Always wear protective eyewear when using tools that may generate splinters.
• Before you start your installation, turn off the head unit, the amplifier if you have one, and
all electrical devices in your audio system, in order to prevent any damages.
• Make sure the location you chose for your components doesn’t hinder the correct
functioning of all mechanic or electric devices in your car.
• For door installations, check the clearance with the windows throughout the range
of the window travel and verify that the woofers magnet does not interfere with
any electrical devices.
• Don’t put cables or install passive crossovers close to electronic gearcases.
• Use extreme caution when cutting or drilling the car plate, verifying there are no electrical
wiring or structural elements underneath.
• Protect conductor with a rubber ring if wires pass through a hole in the plate or with
proper materials if they pass close to heat-generating parts.
• Firmly fix all the additional structures you built to install the various components to the
vehicle chassis through brackets, screws, nuts and bolts, in order to insure stability and
reliability while driving.
Warranty restrictions
Please carefully read warranty terms and keep both the manual and the original box.
HERTZ has restricted warranty, according to the terms written below:
Warranty duration: 2 years
Subject: This warranty is valid only for HERTZ products sold by HERTZ authorised dealers.
Object: Products found to be defective during the warranty period will be repaired or
replaced with an equivalent product at HERTZ’s discretion.
Warranty is void:
1. For damages caused by accidents, abuse, improper operation, water, theft.
2. If after sale service is performed by anyone other than HERTZ authorised service centers.
3. If serial number has been spoiled, altered or removed from the product.
4. For damages caused by overdriving or excessive distortion due to non-linear functioning
of power supply.
HERTZ accepts no liabilities for possible damages that result from disregarding what is
written in this manual.
