117
Note: To view the current video, the network camera must be registered in Camera Policies.
• The layout of the camera view (numbers of rows and columns) and registered network cameras are displayed in
the panel on the right side of the screen.
• The camera view (live video) is displayed on the left side panel. In the default setting, a 2x2 camera view is
displayed. A layout view with up to 4x4 cameras can be displayed.
• Double-clicking the network camera name or dragging to the camera view frame enables viewing of the current
video that is being recorded by the network camera.
The layout can be saved in View - Save Layout As.
Data Service Policies
Data Service Policies is utility software for creating data service policies. The policy types that can be created are shown
below.
Note: To use migration and duplication, a separate backup license must be purchased.
Policy Type Action
Migration Moves recorded video data to another TeraStation
Duplication Copies recorded video data to another TeraStation and synchronizes the data.
Purge Deletes the recorded video data.
The right side of the screen includes tools for creating and updating data service policies. The left side of the screen
shows an overview of all data service policies.
