Buffalo LS441D1604-EU [46/105] Hard drive replacement

2 Click to the right of "Groups".

3 Select the group whose space will be limited.

4 Enable quotas, choose the maximum space the group is allowed, and click OK.

5 Click OK.

6 In Advanced Settings, click to the right of "Users".

7 Select the user who will inherit the group quota settings.

8 Change the user's primary group to the group with the quota, then click OK.

9 Click OK.

10 Click the icon and select Restart to apply the quota settings.

Hard Drive Replacement

If a drive fails, NAS Navigator2 and Settings will show an error message.

Notes:

• Do not replace a running drive while the LinkStation is turned on. Power down the LinkStation before

changing the drive. While the LinkStation is running, never unplug or remove drives without dismounting

them first.

• The replacement drive should be a OP-HD/LS series drive, available from Buffalo. Using a different drive might

cause your LinkStation to malfunction.

• Use a Buffalo OP-HD/LS series drive of the same size or larger for the replacement drive. If a larger drive is

used, the extra space will not be usable in a mirrored RAID array.

• To avoid damaging the LinkStation with static electricity, ground yourself by touching something made of

metal before handling any sensitive electronic parts.

• After a drive is replaced, it will take about 30 minutes before normal file reading and writing are restored.

Settings may not be accessible during this period.

• Do not change the order of the hard drives in the LinkStation. For example, pulling out drive 1 and replacing

it with drive 2 may cause data to be corrupted or lost.

• If a new drive is not recognized after installing it, click Rediscover Disk in Settings.
