Chapter 1 Product Overview

WBMR-HP-GNV2 User Manual 9

Top

AOSS Button To initiate AOSS, hold down this button until the Security LED ashes

(about 1 second). Then, push or click the AOSS button on your wireless

client device to complete the connection. Both devices must be powered

on for this to work.

Antenna connector Screw on the antenna here.
