Buffalo WBMR-HP-GNV2 [31/104] Wireless config

WBMR-HP-GNV2 User Manual 30

Chapter 4 Conguration

Wireless Cong

WPS

WPS Status and Settings.

Parameter Meaning

WPS Enable to use WPS automatic conguration.

External Registrar Enable to accept the external congure requests from other WPS

devices.

Note: External congure requests will not be accepted if AOSS is in use.

AirStation PIN Displays the PIN code of the AirStation. Clicking [Generate PIN]

will generate a new PIN code. This code can be entered into other

wireless devices that support WPS.

Enrollee PIN Enter the PIN code for the other wireless device and click [OK].

WPS status Displays [congured] if all available wireless bands are

congured. Displays [uncongured] if at least one wireless band is

uncongured.
