Buffalo WBMR-HP-GNV2 [12/104] Chapter 2 placing your airstation

WBMR-HP-GNV2 User Manual 11

Chapter 2 - Placing Your AirStation

Vertical Placement

To place unit vertically, attach the stand as shown below.

Antenna Placement

The antenna is included in the package. Screw the antenna clockwise to install.
