Description of the device

For the illustrations, refer to the graphics page.

Illustration A

1 Operation button for Device On / Off

2 Operation button for Function lock

3 Display PM 2.5 Air quality index

4 Operation button for Switch off display

5 Display for fan level

6 Operation button for Auto mode On / Off

7 Fan level operation button

8 Operation button for Sleep mode On / Off

9 Timer display

10 Operation button for Timer

11 Filter service life display

12 Operation button for Filter reset

13 Air quality display and device display

14 Filter cover lock

15 Filter cover

16 Filter tab

17 filter

18 Connection for power supply unit

19 Device sensor

20 Power adapter

Note

The function settings are only possible via the operation

buttons and not via the displays.

Inserting the filter

Before initial start up, the fine filters already installed in

the unit must be unpacked.

1. Turn the device over, and turn the filter cover lock 45

degrees clockwise.

Illustration B

2. Remove the filter cover.

Illustration C

3. Remove the packed filters.

Illustration D

4. Unpack the filters.

Illustration E

5. Insert the unpacked filters. Ensure that the draw

shackles are visible and point inwards.

Illustration F

6. Put on the filter cover and turn the lock 45 degrees

anticlockwise. Turn the device over with the display

facing upwards.

Illustration G

7. Place the device on a level surface. Ensure that a

distance of 30 cm is maintained to each side.

Illustration H

Note

Do not place the device on hot surfaces or in the imme-

diate vicinity of the room heating.

Do not allow any liquids or foreign bodies (e.g. metallic

objects) to enter the device.

8. Insert the plug of the power supply unit into the de-

vice and insert the mains plug into the socket.

Illustration I

The device is ready for operation.

Note

The first time you use the device, we recommend allow-

ing it to run overnight to perform an initial basic cleaning

of your room.

Note

The table with the hours of the display symbols for the

filter service life, see Replacing the filter

Operation

Switching the device on/off

1. To switch on the device: Press the on/off button on

the device.

Illustration I

The device starts automatically.

Note

After the system is switched on, the displays and but-

tons on the control panel light up briefly. The integrated

air quality sensor measures the air quality in the room

automatically.

2. If required, the following functions, for example, can

be set via the operation buttons:

 Fan level

 Auto mode

 Sleep mode

 Timer

3. To switch off the device: Press the On/Off switch of

the device.

The displays and buttons on the control panel go

out. The device is switched off.

Setting auto mode

In automatic mode, the air purifier sets the appropriate

fan level depending on the air quality.

In the event of poor air quality, for example, the fan level

is automatically set high.

Symbol for the auto mode operation button:

 Press the auto mode operation button. The auto-

matic mode is switched on or off.

Setting sleep mode

In sleep mode, the fan runs at the lowest speed and is

therefore very quiet. All light symbols are off.

● Press the sleep mode operation button. The sleep

mode is switched on or off.

Symbol for the sleep mode operation button:

Setting the fan level

Depending on the air quality, the fan level can be man-

ually set to level I, II or III. If the air quality is poor, for ex-

ample to filter out smoke, the blower should run at

maximum speed (level III) for 15 - 20 minutes.

Note

To clean the air effectively, keep windows and doors

closed while the air purifier is switched on.

Symbol for the fan level operation button:
