Accessories

Receiver 1 pc

AC/DC power adaptor 1 pc

AG13 (1.5 V) battery 2 pcs

Audio cable 3.5-3.5 mm 1 pc

Instruction manual 1 pc

Warranty card 1 pc

Consumer information 1 pc

Specifications

FM frequency range 65 - 108 MHz

Supported storages USB/SD/MMC

Adaptor input power AC100-240 ~ 50 Hz / 0.2 A

Adaptor output power DC 6 V / 600 mA

Nominal power consumption 5.4W

Output power 2 W

Nominal voltage (clock) 3 V (1.5 V x 2 AG13 batteries)

Net/Gross weight 0.46 kg/0.58 kg

Unit dimensions 170 mm x 68 mm x 80 mm

Due to continuous improvement of the device, the specifications and functions in the manual

are subject to change without notice.

Troubleshooting guide

Below is a table describing simple measures of eliminating most problems that can emerge

while using this unit. If the below measures do not help, turn to the neares service center or

dealer.

Trouble Cause Solution

Time and date settings are reset after

power outage

AG13 batteries are

absent, inserted

incorrectly or discharged.

Insert AG13 batteries

with correct polarity.

Replace discharged

batteries.
