The vacuum cleaner must be in a horizontal position during operation. Do not lift the vacuum cleaner during

operation.

B&B Trends, S.L. disclaims all liability for damages that may occur to people, animals or objects, for the

nonobservance of these warnings.

PREPARING THE VACUUM CLEANER FOR OPERATION

1. Insert the end of the suction hose to the vacuum cleaner opening so that the markings on the hose end

and the vacuum cleaner housing are opposite each other and turn the hose clockwise to the position .

2. Connect the other end of the hose (handle) with the telescopic suction tube

3. Hold the ring on the pipe and set chosen length putting it in or out.

4. Assemble the appropriate nozzle or brush to the other end of the suction tube.

5. Use the following nozzle and brush for traditional vacuum cleaning with the dust bag module and vacuum

cleaning with the use of water lter module: combination brush, small nozzle, small brush, crevice nozzle,

parquet brush or turbo brush.

6. To clean hard surface-wooden oors, plastic oors, ceramic tiles etc. pull out the brush by pressing the

switch on the

nozzle according to the gure

7. The vacuum cleaner is equipped with an accessory compartment. The compartment open/close with the

use of a slider. To open/close the compartment side the slider downwards/upwards and take out/put away

the desired nozzle

8. The vacuum cleaner may be stored in a horizontal position; in order to this, place

the fastening hook of the combination nozzle/brush into its fastening. The hose may be left attached to the

vacuum cleaner, but it is important to pay attention not to leave it heavily bent during storage.

9. Close the lid.

10. Grab the plug and pull the cord out of the vacuum cleaner.

While pulling out the cord pay attention to yellow stripe which signals the end of the

cord. Further attempts (pulling on cord) may result in damaging the cord

• Plug in the appliance

Before switching on the vacuum cleaner with the on/off button, make sure that the

appropriate system is installed in the container

11. Switch on the vacuum cleaner by pressing the “on/off” button.

In order to prepare the vacuum cleaner for wet operation additionally:

12. Assemble the spray unit-the suction hose handle attachment.

13. Attach the end of the hose (sleeve) to the telescopic suction tube and insert the other of the hose in the

small atomizing nozzle or the large atomizing nozzle until you hear a characteristic click.

14. Use the following nozzle for the wet vacuuming and wet cleaning function or to pick up water: large

atomizing nozzle, small atomizing nozzle

15. Slide the stub pipe valve plug downwards

• Insert the stub pipe of the hose to the valve in the vacuum cleaner housing.

• Make sure the stub pipe of the fastenings snap shut.
