ATTENTION!

At the time of installation of the device is rec-

ommended Wear safety glasses. Loosen the nut

(1) on the top of the water trap (4) with a pipe

wrench (Fig. 3.1). relative humidity not more

than 80%. Loosen the nut (2) on the top of the

extension pipe. Remove the extension pipe.

Loosen the nut (3) at the bottom of the washing

ange.

Push the washing ange upwards through drain

hole of the sink and remove it (Fig. 3.2).

CLEAN THE WASH FAN WRAPPING PLACE

FROM THE SEALANT OR THE GARBAGE.

NOTE: It may be necessary to expand the drain

hole for installation ange fastening disposer.

Equipment for extending the drainage hole is

purchased separately.

3. DISASSEMBLY OF THE ASSEMBLY UNIT

Turn over the assembly (Fig.4.1) and loosen the

three xing screws (1) The access to the ring (2).

Disconnect the retaining ring from the ange

with a screwdriver. Now the assembly unit can

be disassembled.

4. ATTACHING THE FIXING ASSEMBLY TO

WASHING Fig.5.1.

1. Install one or two rubber gaskets (2) under the

washing ange (1). Make sure that The drainage

hole is not clogged, and set to ange washer /

gasket. In order to The ange of the sink became

in place, you need to crush it with a heavy load.

(To avoid scratches, use a towel as a lining.)

2. Put the second rubber part on the bottom of

the kitchen sink a gasket (2), a cardboard gasket

(optional) (3) and a metal support ring (4) (at

side up).

3. While holding the second rubber gasket, card-

board padding (optional) and a metal support

ring, put the mounting ring (5) on the ange of

the sink so that it aligned with the support ring.

4. Pressing tightly to the bottom of the sink rub-

ber gasket, cardboard gasket, support ring and

mounting ring, slide the snap ring (7) onto the

ange of the sink so that it snaps into the ange

groove.

5. Tighten the three xing screws (6) to The x-

ing assembly was tight and evenly pressed to

the sink.

5. CLEANING THE DRAIN PIPE

If you do not clean the drain pipe, it can clog.

1. Remove the water trap. (Fig.6.1)

2. Using a cleaner, remove all solid precipita-

tion in the horizontal part of the drainage pipes,

moving with side of the siphon towards the main

pipe.

IF THE DISHWASHER WILL NOT BE CONNECT-

ED TO THE DISPOSER, GO TO PART 7 OF THIS

INSTRUCTION

6. CONNECTING THE DISHWASHER MA-

CHINES AND TRANSFER CONNECTION

If the sink is full of liquid it can be discharged

into the disposer through the inlet in its upper

parts. (Fig. 7.2)

On all models inside the intake pipe there is par-

tition. The partition must be removed (Fig. 7.1).

REMOVING THE PLATE / PARTITION

1. Place the disposer on one side and place it

screwdriver into the connection for the dish-

washer, pushing it until it will not rest against the

partition in the end of the branch pipe.

2. With several blows of the hammer, knock out

the septum in the branch pipe (Fig. 7.1).

3. Remove the embossed partition from the

disposer bowl. If necessary to connect the dish-

washer, then it should be connected to the inlet

of the overow outlet pipes To connect to the

overow inlet, remove the exhaust pipe cover by

unscrewing the cover (Fig. 7.3).

7. CONNECTING THE DISPOSER TO THE FIXING

UNIT ATTENTION!

To avoid injury, follow the so that during the re-

moval and installation of a part Your body was

not under the disposer; during the installation it

is possible to drop it.

Remove any objects from the grinding chamber

product before installing it on the sink.

1. Install the product in such a way that provide

easy access to the restart button engine located

in the lower part of the body. Do not block this

place with any objects.

2. Place the disposer with three mounting loops

(1) into the sliding position by mounting rails (2).

(Fig. 8.1)

3. Lift the disposer, insert the top end (installa-

tion gasket) in the mounting and turn the setting

ring to the right (with a wrench or adjustable pli-

ers) until the mounting loops are xed (3) with

respect to the mounting rails (Fig. 8.2).

Make sure that all three mounting loops are

locked. Disposer is installed.

4. Run water into the sink, then check the con-

nections for leaks.
