5. Insert the noise absorbing screen into the

drain hole at side up. (Fig.8.3)

8. CONNECTING THE OUTLET PIPE

• To the DRAIN PIPE ATTENTION!

• It is recommended to wear protective goggles

when installing the disposer.

• For all models, the drain pipe is connected us-

ing a screw connection (Fig. 9.2). First connect

the hydraulic lock to the disposer and then to

the drain. For the connection a siphon with

smooth walls should be used.

• Use a sanitary sealant only for connecting the

ange of the sink with the disposer.

• Do not use sealants for threaded pipe connec-

tions or anaerobic screwed sealants. They can

damage the product.

• Regularly check the disposer and ttings for

water leaks, since leaks water can cause dam-

age to property.

• The manufacturer is not responsible for dam-

age to property as a result of water leaks.

INSTALLING THE DRAINAGE SYSTEM

1. Put the ange (2) on the drain pipe Insert the

rubber seal (1). Fasten drain tube, tightly pulling

it to the body disposer with screws (4). (Fig. 9.1)

9. CONNECTING THE DISPOSER TO THE ELEC-

TRICAL NETWORK

ATTENTION! ELECTRIC SHOCK CURRENT

To prevent electric shock, turn off the power be-

fore installing or servicing the product.

If you are not qualied enough, call an electrician

to connect the product to the power.

If a three–pin grounding–type plug is used to

connect a three–contact outlet with ground.

Do not modify the design of the plug supplied

with the device.

Improper equipment grounding may cause elec-

tric shock current.

All electrical connections must comply with the

electrical and norms.

Do not connect the ground to the feed pipe gas.

Do not power on the distribution shield until you

have installed the sockets with proper ground-

ing.

If the power cord is damaged, it must be re-

placed at the service center.

NOTE: Access to a grounded outlet is required.

Installing all additional outlets must be carried

out by a qualied electrician, and all outlets must

be properly grounded.

Turn ON/OFF device

Depending on the models BORT disposer are

equipped with two types of control: a wireless

(wall) switch or a pneumatic switch.

Wireless (wall) switch

The disposer of the “Control and FullControl”

series are equipped with a wireless wall mount

switch.

The switch should be located in a convenient

(safe for children) place above the table top.

For instal the switch to the wall, use double–

sided tape.

For activate / deactivate the device, hold down

the key for 2–3 seconds.

Battery type: Voltage: 12V; Size: A27

Air switch

Disposer is equipped with an air switch and a

connecting pipe (except “Control” series).

INSTALLATION OF AIR SWITCH

1. Drill a hole with a diameter of 32 mm in suit-

able top or top the panel of a sink. Some sinks

may already have a suitable A hole for the open-

ing of which is necessary remove the cover.

2. Unscrew the nut from the body of the push

button, while holding the stainless steel washer

and rubber gasket in place. Place one end of the

PVC tube on the spout on the body Press the

other end to A hole in the table top and a nut lo-

cated under the countertop. (Fig. 10.2)

3. Place the push button housing in the hole and

tighten the nut underneath countertop (enough

arm effort). Do not use the key to tighten nut.

(Fig. 10.3)

4. Take the other end of the duct and tightly put

it on the spout of the air switch located on the

bottom of the disposer. (Fig.10.4) Hand tighten

the clamping nut. The disposer installation is

complete. Before using the product, read all of

the instructions. operation and safety contained

in paragraph 10 of this manual. In conclusion, in-

stall the plug in the sink in the Closed position.

Fill the sink with water, Remove the plug and

check the connections on the a water leakage.

10. ATTENTION! IMPORTANT INSTRUCTIONS

FOR

SAFETY

• If the air switch does not work, remove the plug

power supply from the outlet and check the air

duct pneumatic switch and delivered to the
