«Vacuum and packing» vacuuming/packing mode

button (14)

- To vacuum or seal food products or things, press the

«Vacuum and packing» button (14), after the process

is completed, the vacuuming/packing mode will

automatically turn o󰀨.

- You can stop the vacuuming/packing process at any

time by pressing the «Vacuum and packing» button

(14) again.

- The light indicator of the «Vacuum and packing»

button (14) has two indication modes:

1. The indicator lights up constantly – the vacuuming/

vacuum bag packing mode is on, after vacuuming/packing

the bag, the indicator goes out.

2. The indicator is blinking – the «pause» mode is on.

«Dry/Wet» packing mode selection button (15)

- To select the product packing mode, press the

«Mode» button (15), the selected packing mode is

displayed by the corresponding light indicator «Dry/

Wet».

«Cancel» operation mode cancel button (16)

- You may stop the operation of the vacuum sealer by

pressing the «Cancel» button (16).

- «Indicator» vacuum sealer operating state light

indicator (17)

- The light indicator (17) turns on when the top cover

(1) is closed; if the top cover (1) of the vacuum

sealer is not closed, the indicator (17) will not light up

and the vacuum sealer will not turn on.

USING THE VACUUM SEALER

• Remove the power cord, which is located in its storage

place on the lower part of the vacuum sealer body and

straighten it to its full length.

• Install and use the vacuum sealer on a dry, at and

stable surface, away from heat sources, open ames

and direct sunlight. When installing the vacuum sealer,

leave a free space of about 10 cm on all sides of the

device.

• The electrical outlet must be easily accessible so that

the power plug can be easily pulled out of the electrical

outlet if necessary.

• Open the top cover (1) by simultaneously pressing the

latches (10) (Fig. 1).

• Raise the pressure frame (2), place a vacuum lm roll

(18) in the compartment (7), lower the pressure frame

(2).

• Pull out the lm so that the edge of the lm overlaps

the heating element (5) and protrudes slightly beyond

the vacuum sealer body (Fig. 2).

• Close the top cover (1) until the latches (10) click (Fig.

3).

• Plug the power cord into an electrical outlet.

• To seal the edge of the lm, press the «Packing»

button (13), the button indicator (13) will light up, after

sealing the edge of the lm, the indicator will go out.

Note: in case of improper sealing, you may retreat some

distance from the previous sealing and make a new

sealing of the lm.
