Fig.15
Fitting the casing
Remove the protective film on the casing:
- offer the casing up (fig. 14)
- engage hooks N in notches R operation 1
- fit the top of the panel in place
- close the panel mounting clamps (fig. 15)
N.B. It is essential to refit the locking screw A
A
9. Fitting the casing
1
N
R
Fig.14
