Appendix- 47 -
English
4-1-1 EasyTune 4 Installation
Powerful utility that integrates the overclocking and hardware monitoring functions
5. Click "HELP".
(4)
(3)
3. Click "Finish" to restart computer.
4. Right Click the icon to
start "EasyTune 4".
(1)
(2)
1. Click "EasyTune4" item.
2. Click "Next".
Chapter 4 Appendix
4-1 Unique Software Utilities
