![Gigabyte GA-8I845GVM-775 [6/72] Ga 8i845gvm775 motherboard layout](/img/pdf.png)
Gigabyte GA-8I845GVM-775 [6/72] Ga 8i845gvm775 motherboard layout
![Gigabyte GA-8I845GVM-775 [6/72] Ga 8i845gvm775 motherboard layout](/views2/1115110/page6/bg6.png)
- 6 -
GA-8I845GVM775 Motherboard Layout
KB_MS
ATX_12V
CPU_FAN
LGA775
AUDIO
Intel 845GV
SPDIF_IO
CODEC
CI
VGA
LPT
USB
LAN
IT8712F
Intel ICH4
F_PANEL
BIOS
PCI1
PCI2
RTL
8100C
F_AUDIO
F_USB1
BAT
ATX
IDE1
FDD
CLR_CMOS
SYS_FAN
CD_IN
GA-8I845GVM775
COMB
DDR1
DDR2
PCI3
COMA
IDE2
AUX_IN
R_USB
