- 11 - Hardware Installation
USB
Chipset
- Up to 14 USB 2.0/1.1 ports
(Note 6)
(8 on the back panel, 6 via the USB
brackets connected to the internal USB headers)
j
- Up to 12 USB 2.0/1.1 ports
(Note 6)
(8 on the back panel, 4 via the USB
brackets connected to the internal USB headers)
k
NEC D720200F1 chip:
- Up to 2 USB 3.0 ports on the back panel
Internal
1 x 24-pin ATX main power connector
Connectors
1 x 4-pin ATX 12V power connector
1xoppydiskdriveconnector
1 x IDE connector
8 x SATA 3Gb/s connectors
1 x CPU fan header
2 x system fan headers
1 x power fan header
1 x front panel header
1 x front panel audio header
1 x CD In connector
1 x S/PDIF In header
1 x S/PDIF Out header
3 x USB 2.0/1.1 headers
j
2 x USB 2.0/1.1 headers
k
1 x clearing CMOS jumper
Back Panel
1 x PS/2 keyboard or PS/2 mouse port
Connectors
1 x coaxial S/PDIF Out connector
1 x parallel port
1 x serial port
6 x USB 2.0/1.1 ports
2 x USB 3.0/2.0 ports
1 x RJ-45 port
3 x audio jacks (Line In/Line Out/Microphone)
I/O Controller
iTE IT8720 chip
Hardware Monitor
System voltage detection
CPU/System temperature detection
CPU/System/Power fan speed detection
CPU overheating warning
CPU/System/Power fan fail warning
CPU/System fan speed control
(Note 7)
j
Only for P55 chipset.
k
Only for H55 chipset.
