- 51 - BIOS Setup
Link Detected Displays transmission speed.
Cable Length Displays the approximate length of the attached LAN cable.
Note: The Gigabit hub will only operate at a speed of 10/100 Mbps in MS-DOS mode; it will operate at a
normal speed of 10/100/1000 Mbps in Windows mode or when the LAN Boot ROM is activated.
When a Cable Problem Occurs...
Ifacableproblemoccursonaspeciedpairofwires,theStatuseldwillshowShort and then length
shown will be the approximate distance to the fault or short.
Example:
Part1-2 Status = Short / Length = 2m
Explanation: A fault or short might occur at about 2m on Part 1-2.
Note: Part 4-5 and Part 7-8 are not used in a 10/100 Mbps environment, so their Statuseldswillshow
Open, and the length shown is the approximate length of the attached LAN cable.
Onboard LAN Boot ROM
Allows you to decide whether to activate the boot ROM integrated with the onboard LAN chip.
(Default: Disabled)
Onboard USB 3.0 Controller (NEC USB 3.0 Controller)
Enables or disables the NEC USB 3.0 controller. (Default: Enabled)
Onboard SATA/IDE Device (GIGABYTE SATA2, IDE and GSATA2_6/7 Connectors)
Enables or disables the IDE and SATA controllers integrated in the GIGABYTE SATA2 chip.
(Default: Enabled)
Onboard SATA/IDE Ctrl Mode (GIGABYTE SATA2, IDE and GSATA2_6/7 Connectors)
EnablesordisablesRAIDfortheSATAcontrollerintegratedintheGIGABYTESATA2chiporcongures
the SATA controller to AHCI mode.
IDE DisablesRAIDfortheSATAcontrollerandcongurestheSATAcontrollertoIDE
mode. (Default)
AHCI CongurestheSATAcontrollertoAHCImode.AdvancedHostControllerInterface
(AHCI)isaninterfacespecicationthatallowsthestoragedrivertoenableadvanced
Serial ATA features such as Native Command Queuing and hot plug.
RAID/IDE Enables RAID for the SATA controller; the IDE controller still operates in IDE mode.
Onboard Serial Port 1
EnablesordisablestherstserialportandspeciesitsbaseI/Oaddressandcorrespondinginterrupt.
Options are: Auto, 3F8/IRQ4 (default), 2F8/IRQ3, 3E8/IRQ4, 2E8/IRQ3, Disabled.
Onboard Parallel Port
Enablesordisablestheonboardparallelport(LPT)andspeciesitsbaseI/Oaddressandcorrespond-
ing interrupt. Options are: 378/IRQ7 (default), 278/IRQ5, 3BC/IRQ7, Disabled.
Parallel Port Mode
Selects an operating mode for the onboard parallel (LPT) port. Options are: SPP (Standard Parallel Port)
(default), EPP (Enhanced Parallel Port), ECP (Extended Capabilities Port), ECP+EPP.
