- 41 - BIOS Setup

tWTP

Options are: Auto (default), 1~31.

tWL

Options are: Auto (default), 1~10

tRFC

Options are: Auto (default), 1~255.

tRTP

Options are: Auto (default), 1~15.

tFAW

Options are: Auto (default), 1~63.

Command Rate(CMD)

Options are: Auto (default), 1~3.

>>>>> Channel A/B Misc Timing Control

B2B CAS Delay

Options are: Auto (default), 1~31.

Round Trip Latency

Options are: Auto (default), 1~255.
