Gigabyte GA-P55-US3L (REV. 2.1) [30/112] Phase led

Hardware Installation - 30 -

18) PHASE LED

The number of lighted LEDs indicates the CPU loading. The higher the CPU loading, the more the

numberoflightedLEDs.ToenablethePhaseLEDdisplayfunction,pleaserstenableDynamicEnergy

Saver

™

2. Refer to Chapter 4, "Dynamic Energy Saver

™

2," for more details.
