BIOS Setup - 48 -
2-6 Integrated Peripherals
SATA AHCI Mode (Intel H55 Chipset)
AllowsyoutodecidewhethertoconguretheSATAcontrollerintegratedintheIntelH55ChipsettoAHCI
mode.
IDE CongurestheSATAcontrollertoIDEmode.(Default)
AHCI CongurestheSATAcontrollertoAHCImode.AdvancedHostControllerInterface
(AHCI)isaninterfacespecicationthatallowsthestoragedrivertoenableadvanced
Serial ATA features such as Native Command Queuing and hot plug.
SATA Port0-3 Native Mode (Intel H55 Chipset)
SpeciestheoperatingmodeoftheintegratedSATAcontrollers.
Disabled Allows the SATA controllers to operate in Legacy IDE mode. In Legacy mode the
SATA controllers use dedicated IRQs that cannot be shared with other device. Set
this option to Disabled if you wish to install operating systems that do not support
Native mode.
Enabled Allows the SATA controllers to operate in Native IDE mode. Enable Native IDE mode
if you wish to install operating systems that support Native mode. (Default)
USB Controllers
Enables or disables the integrated USB controllers. (Default: Enabled)
Disabled will turn off all of the USB functionalities below.
USB Legacy Function
Allows USB keyboard to be used in MS-DOS. (Default: Enabled)
USB Storage Function
DetermineswhethertodetectUSBstoragedevices,including USB ash drives and USB hard drives
during the POST. (Default: Enabled)
CMOS Setup Utility-Copyright (C) 1984-2009 Award Software
Integrated Peripherals
SATA AHCI Mode [IDE]
SATA Port0-3 Native Mode [Enabled]
USB Controllers [Enabled]
USB Legacy Function [Enabled]
USB Storage Function [Enabled]
Azalia Codec [Auto]
Onboard H/W LAN [Enabled]
Green LAN [Disabled]
SMART LAN [Press Enter]
Onboard LAN Boot ROM [Disabled]
Onboard SATA/IDE Device [Enabled]
Onboard SATA/IDE Ctrl Mode [IDE]]
Onboard Serial Port 1 [3F8/IRQ4]
Onboard Parallel Port [378/IRQ7]
Parallel Port Mode [SPP]
higf
: Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
Item Help
Menu Level
