BIOS Setup - 42 -
Advanced Voltage Settings
CMOS Setup Utility-Copyright (C) 1984-2009 Award Software
Advanced Voltage Settings
****** Mother Board Voltage Control ******
Voltage Types Normal Current
-----------------------------------------------------------------------------
>>> CPU
Load-Line Calibration [Auto]
CPU Vcore 1.26875V [Auto]
QPI/Vtt Voltage 1.100V [Auto]
>>> MCH/ICH
PCH Core 1.050V [Auto]
CPU PLL 1.800V [Auto]
>>> DRAM
DRAM Voltage 1.500V [Auto]
DRAM Termination 0.750V [Auto]
higf
: Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
Item Help
Menu Level
>>> CPU
Load-Line Calibration
Enables or disables Load-Line Calibration. Enabling this feature adjusts Vdroop, keeping the CPU
voltage more constant under light and heavy CPU load. Disabled sets the CPU voltage following Intel
specications.(Default:Auto)
Note: Enabling Load-Line Calibration may result in damage to your CPU or reduce the useful life of the
CPU.
CPU Vcore
The default is Auto.
QPI/Vtt Voltage
The default is Auto.
>>> MCH/ICH
PCH Core
The default is Auto.
CPU PLL
The default is Auto.
>>> DRAM
DRAM Voltage
The default is Auto.
DRAM Termination
The default is Auto.
