Gigabyte GA-H55M-S2V (REV. 1.3) [10/80] 2 product specifications
![Gigabyte GA-H55M-S2V (REV. 1.3) [10/80] 2 product specifications](/views2/1115292/page10/bga.png)
- 10 -Hardware Installation
1-2 Product Specications
CPU
Support for Intel
®
Core
™
i7 processors/Intel
®
Core
™
i5 processors/Intel
®
Core
™
i3
processors/Intel
®
Pentium
®
processors in the LGA1156 package
(Go to GIGABYTE's website for the latest CPU support list.)
L3 cache varies with CPU
Chipset
Intel
®
H55 Express Chipset
Memory
2 x 1.5V DDR3 DIMM sockets supporting up to 16 GB of system memory
(Note 1)
Dual channel memory architecture
Support for DDR3 1666 (O.C.)/1333/1066/800 MHz memory modules
Support for non-ECC memory modules
Support for Extreme Memory Prole (XMP) memory modules
(Go to GIGABYTE's website for the latest supported memory speeds and
memory modules.)
Onboard Graphics
Integrated in the Chipset:
- 1 x DVI-D port
(Note 2)(Note 3)
j
- 1 x D-Sub port
(Note 2)
Audio
Realtek ALC888B codec
High Denition Audio
2/4/5.1/7.1-channel
(Note 4)
LAN
1 x Realtek RTL8111E chip (10/100/1000 Mbit)
Expansion Slots
1 x PCI Express x16 slot, running at x16
(The PCIEX16 slot conforms to PCI Express 2.0 standard.)
1 x PCI Express x1 slot
2 x PCI slots
Storage Interface
Chipset:
- 6 x SATA 3Gb/s connectors supporting up to 6 SATA 3Gb/s devices
USB
Chipset:
- Up to 12 USB 2.0/1.1 ports (8 on the back panel, 4 via the USB brackets
connected to the internal USB headers)
Internal
1 x 24-pin ATX main power connector
Connectors
1 x 4-pin ATX 12V power connector
6 x SATA 3Gb/s connectors
1 x CPU fan header
1 x system fan header
1 x front panel header
1 x front panel audio header
2 x USB 2.0/1.1 headers
1 x clearing CMOS jumper
j
Only for GA-H55M-S2V.
