- 43 - BIOS Setup
2-6 Integrated Peripherals
SATA AHCI Mode (Intel H55 Chipset)
Allows you to decide whether to congure the SATA controllers integrated in the Intel H55 Chipset to
AHCI mode.
IDE Congures the SATA controllers to IDE mode. (Default)
AHCI Congures the SATA controllers to AHCI mode. Advanced Host Controller Interface
(AHCI) is an interface specication that allows the storage driver to enable advanced
Serial ATA features such as Native Command Queuing and hot plug.
SATA Port0-3 Native Mode (Intel H55 Chipset)
Species the operating mode of the integrated SATA controllers.
Disabled Allows the SATA controllers to operate in Legacy IDE mode. In Legacy mode the
SATA controllers use dedicated IRQs that cannot be shared with other device. Set
this option to Disabled if you wish to install operating systems that do not support
Native mode.
Enabled Allows the SATA controllers to operate in Native IDE mode. Enable Native IDE mode
if you wish to install operating systems that support Native mode. (Default)
USB Controllers
Enables or disables the integrated USB controllers. (Default: Enabled)
Disabled will turn off all of the USB functionalities below.
USB Legacy Function
Allows USB keyboard to be used in MS-DOS. (Default: Enabled)
USB Storage Function
Determines whether to detect USB storage devices, including USB ash drives and USB hard drives
during the POST. (Default: Enabled)
CMOS Setup Utility-Copyright (C) 1984-2010 Award Software
Integrated Peripherals
SATA AHCI Mode [IDE]
SATA Port0-3 Native Mode [Enabled]
USB Controllers [Enabled]
USB Legacy Function [Enabled]
USB Storage Function [Enabled]
Azalia Codec [Auto]
Onboard H/W LAN [Enabled]
Green LAN [Disabled]
SMART LAN [Press Enter]
Onboard LAN Boot ROM [Disabled]
higf
: Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
Item Help
Menu Level
