- 11 - Hardware Installation
USB
Chipset:
- Up to 12 USB 2.0/1.1 ports (8 on the back panel, 4 via the USB brackets
connected to the internal USB headers)
Internal
1 x 24-pin ATX main power connector
Connectors
1 x 4-pin ATX 12V power connector
1xoppydiskdriveconnector
1 x IDE connector
6 x SATA 3Gb/s connectors
1 x CPU fan header
2 x system fan headers
1 x power fan header
1 x front panel header
1 x front panel audio header
1 x CD In connector
1 x S/PDIF In header
1 x S/PDIF Out header
2 x USB 2.0/1.1 headers
1 x serial port header
1 x clearing CMOS jumper
Back Panel
1 x PS/2 keyboard/mouse port
Connectors
1 x D-Sub port
(Note 2)
1 x DVI-D port
(Note 2) (Note 3) (Note 4)
1 x HDMI port
(Note 2) (Note 4)
1 x optical S/PDIF Out connector
8 x USB 2.0/1.1 ports
1 x RJ-45 port
6 x audio jacks (Center/Subwoofer Speaker Out/Rear Speaker Out/
Side Speaker Out/Line In/Line Out/Microphone)
I/O Controller
iTE IT8720 chip
Hardware Monitor
System voltage detection
CPU/System temperature detection
CPU/System fan speed detection
CPU overheating warning
CPU/System fan fail warning
CPU/System fan speed control
(Note 8)
