- 41 - BIOS Setup
tFAW
Options are: Auto (default), 1~63.
Command Rate(CMD)
Options are: Auto (default), 1~3.
>>>>> Channel A/B Misc Timing Control
Static tRD
Options are: Auto (default), 1~31.
Advanced Voltage Settings
>>> CPU
Load-Line Calibration
Enables or disables Load-Line Calibration. Enabling this feature adjusts Vdroop, keeping the CPU
voltage more constant under light and heavy CPU load. Disabled sets the CPU voltage following Intel
specications.(Default:Disabled) Note: Enabling Load-LineCalibrationmayresult in damage to your
CPU or reduce the useful life of the CPU.
CPU Vcore
The default is Auto.
Dynamic Vcore(DVID)
The default is Auto.
QPI/Vtt Voltage
The default is Auto.
>>> MCH/ICH
PCH Core
The default is Auto.
CPU PLL
The default is Auto.
CPU VAXG Voltage
The default is Auto.
CMOS Setup Utility-Copyright (C) 1984-2009 Award Software
Advanced Voltage Settings
****** Mother Board Voltage Control ******
Voltage Types Normal Current
-----------------------------------------------------------------------------
>>> CPU
Load-Line Calibration [Disabled]
CPU Vcore 1.18750V [Auto]
Dynamic Vcore(DVID) +0.00000V [Auto]
QPI/Vtt Voltage 1.100V [Auto]
>>> MCH/ICH
PCH Core 1.050V [Auto]
CPU PLL 1.800V [Auto]
CPU VAXG Voltage 1.2200V [Auto]
>>> DRAM
DRAM Voltage 1.500V [Auto]
DRAM Termination 0.750V [Auto]
Ch-A Data VRef. 0.750V [Auto]
Ch-B Data VRef. 0.750V [Auto]
Ch-A Address VRef. 0.750V [Auto]
Ch-B Address VRef. 0.750V [Auto]
higf
: Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
Item Help
Menu Level
