C. Conguring a RAID array in RAID BIOS

EntertheRAIDBIOSsetuputilitytocongureaRAIDarray.Skipthisstepandproceedwiththeinstallationof

Windowsoperatingsystemforanon-RAIDconguration.

Step 1:

After the POST memory test begins and before the operating system boot begins, look for a message which

says"Press<Ctrl-I>toenterCongurationUtility"(Figure2).Press<Ctrl>+<I>toentertheRAIDCongura-

tion Utility.

Figure 2

Step 2:

After you press <Ctrl> + <I>, the MAIN MENU screen will appear (Figure 3).

Create RAID Volume

If you want to create a RAID array, select Create RAID Volume in MAIN MENU and press <Enter>.

Figure 3

Intel(R) Rapid Storage Technology - Option ROM - 10.1.0.1008

RAID Volumes :

Nonedened.

Physical Devices :

Port Device Model Serial # Size Type/Status(Vol ID)

0 ST3120026AS 3JT354CP 111.7GB Non-RAID Disk

1 ST3120026AS 3JT329JX 111.7GB Non-RAID Disk

Press<CTRL-I>toenterCongurationUtility..

Intel(R) Rapid Storage Technology - Option ROM - 10.1.0.1008

3. Reset Disks to Non-RAID

4. Recovery Volume Options

RAID Volumes :

Nonedened.

Physical Deivces :

Port Device Model Serial # Size Type/Status(Vol ID)

0 ST3120026AS 3JT354CP 111.7GB Non-RAID Disk

1 ST3120026AS 3JT329JX 111.7GB Non-RAID Disk

[

]-Select [ESC]-Exit [ENTER]-Select Menu

[ DISK/VOLUME INFORMATION ]

[ MAIN MENU ]

1. Create RAID Volume

2. Delete RAID Volume

5. Exit
