- 41 - BIOS Setup
Command Rate(CMD)
Options are: Auto (default), 1~3.
>>>>> Channel A/B Misc Timing Control
IO Latency
Options are: Auto (default), 1~31.
Round Trip Latency
Options are: Auto (default), 1~255.
Advanced Voltage Settings
CMOS Setup Utility-Copyright (C) 1984-2010 Award Software
Advanced Voltage Settings
******
Mother Board Voltage Control
******
Voltage Types Normal Current
-----------------------------------------------------------------------------
>>> CPU
CPU Vcore 1.180V [Auto]
x Dynamic Vcore(DVID) +0.000V Auto
QPI/Vtt Voltage 1.050V [Auto]
Graphics Core 1.220V [Auto]
x Graphics DVID +0.000V Auto
>>> MCH/ICH
PCH Core 1.050V [Auto]
DRAM Voltage 1.500V [Auto]
higf
: Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
Item Help
Menu Level
>>> CPU
CPU Vcore
The default is Auto.
Dynamic Vcore(DVID)
ThisoptioniscongurableonlywhenCPU Vcore is set to Normal. The default is Auto.
QPI/Vtt Voltage
The default is Auto.
Graphics Core
The default is Auto.
Graphics DVID
ThisoptioniscongurableonlywhenGraphics Core is set to Normal. The default is Auto.
>>> MCH/ICH
PCH Core
The default is Auto.
DRAM Voltage
The default is Auto.
