Hikvision DS-2CD8433F-E(I) [48/95] Configuring audio settings

User Manual of Network Camera

Frame Rate:

Set the frame rate to 1/16~25 fps. The frame rate is to describe the frequency at

which the video stream is updated and it is measured by frames per second (fps).

A higher frame rate is advantageous when there is movement in the video stream,

as it maintains image quality throughout.

Max. Bitrate:

Set the max. bitrate to 32~16384 Kbps. The higher value corresponds to the

higher video quality, but the higher bandwidth is required.

Video Encoding:

When the Stream Type of the camera is main stream, the Video Encoding

standard can be set to H.264.

When the Stream Type of the camera is sub-stream, the Video Encoding standard

can be set to H.264, MJPEG.

Profile:

Basic profile, Main Profile and High Profile for coding are selectable.

I Frame Interval:

Set the I-Frame interval to 1~400.

SVC:

Scalable video coding is an extension of the H.264/AVC standard. The technology

encodes the video signal with layers; the basic layer and several enhanced layers

and it is adaptive to the network condition to transfer different video streams. For

example, when the bandwidth is limited, only the basic layer data is encoded and

transferred. You can enable the function when you want to see the video with

several terminals, such as the mobile phone with 3G network, or the personal

computer with IP network.

4. Click to save the settings.

6.4.2 Configuring Audio Settings

Steps:

1. Enter the Audio Settings interface

Configuration > Basic Configuration > Video / Audio > Audio

Or Configuration > Advanced Configuration > Video / Audio > Audio

Figure 6-18 Audio Settings

2. Configure the following settings.
