Activating the alarm
Example: Wake-up alarm.
┠Alarm Clocks┨┠Morning Call┨┠Alarm Status┨┠Alarm on┨.
Deactivating the alarm
Example: Wakeup alarm.
┠Alarm Clocks┨┠Morning Call┨┠Alarm Status┨┠Alarm off┨.
Ending the alarmfunction
Menu[7] Alarmfunction is ended.
Voice activation
When the voiceactivation functionis switchedon, the display is
switched offafter a certain period ofsilence and activated again on
detecting a noise.
Selecting the time for automaticdeactivation
Example: 30 seconds.
┠Voice Activation┨┠Close Video Time┨┠30 seconds┨.
Switching voice activation off
┠Voice Activation┨┠Close Video Time┨┠Never┨.
Selecting the sensitivity for voice activation
Example: High.
┠Voice Activation┨┠Activation Sensitivity┨┠High┨.
If ┠Activation Sensitivity┨ is set to ┠Never┨ and a ┠Close Video Time┨ is
set,the displayis switched offpermanently.Only the sound is
transmittedand played.
If ┠Activation Sensitivity┨ is set to ┠Never┨ and┠Close Video Tim e ┨ to ┠Never┨,
the sound and visual display are switched on permanently.
Displaying video recordings
┠Video Review┨ Selectthefolder,select the videofile.
The video recording is played.
Displaying photo recordings
┠Photo Album┨ Selectthe folder, select the video file.
T he photosin the fileare displayed.
Bottom [9] or Top [6] Select next/previous image,
respectively.
Basic settings
Date and time
┠Settings┨┠Date and Time┨┠Date┨ Set the date.
┠Settings┨┠Date and Time┨┠Time┨ Set the time.
┠Settings┨┠Date and Time┨┠Time Format┨┠12 hours┨ or
┠24 hours┨.
Function assignment to buttons
The Top [6]and Bottom [9]buttonscanbe assigned different
functions.Eitherthevolume can be adjusteddirectlyor they are
used to switch between the various transmitter units.
┠Settings┨┠Up & Down Buttons Function┨┠Volume Control┨
The Top [6]and Bottom [9]buttons adjust the volume.
┠Settings┨┠Up 
& Down Buttons Function┨
┠Camera Selection┨ The Top [6] and Bottom [9]buttons
switch betweenthevarioustransmitterunits.
Background image
┠Settings┨┠Background Display┨┠Show Image ┨
Background image on.
┠Settings┨┠Background Display┨┠Hide Image┨
Background image off.
Systeminformation
┠Settings┨┠System Information┨ Systeminformation is
displayed.
Activating motion detection
When motion detection is activated,the equipment can be setto
issuea motion alarm or start a video recording if a movementis
detected.
Selecting the sensitivity for motion detection
Example: High.
┠Motion Detection┨┠Motion Detection┨┠High┨.
Activating automatic recording
In order to make a recording,a micro SD card(notincluded) must be
installedin the receiver unit ).
┠Motion Detection┨┠Motion Detection Recording┨┠Enable┨
A red dot lights up at the top leftofthedisplay.
Recording begins when a movement is detected.Recordingcontin-
ues for approx. 10 sec.after a movement is detected. At the same
time,the red dot at thetopleftof the display flashes and the number
of seconds recorded appears beside it.
All the videosrecordedin one day are stored in a separate
folder.
Deactivating automatic recording
┠Motion Detection┨┠Motion Detection Recording┨┠Disable┨.
Activating themotion detectionalert
┠Motion Detection┨┠Motion Detection Alert┨┠Enable┨.
An acousticalarmis issued when a movement is detected.
Deactivating the motion detection alert
┠Motion Detection┨┠Motion Detection Alert┨┠Disable┨.
Power adapter plug, transmitter unit
Using the energy-efficient power adapterplug
FKS106HSC-0501000E(input100-240 V
AC
, output5 V
DC
,
1000 mA) the zeroload is approx.0 W. The average efficiencyis
approx.70.3%. The maximumpower consumption is approx.5.4 W.
Power adapter plug, receiver unit
Using the energy-efficient power adapterplug
FKS106HSC-0501000E(input100-240 V
AC
, output5 V
DC
,
1000 mA) the zeroload is approx.0 W. The average efficiencyis
approx.70.3%. The maximumpower consumption is approx.3.7 W.
Service hotline
In the case of technical problems,contactourService hotline.
Switzerland: Tel. 0900 00 1675 (national charges,Swisscom at time
of going toprint:CHF 2.60/min).
In the case of claimsunder the termsof guarantee,contact your
salesoutlet.
Maintenance
Clean the surfaceof the housing with a soft,fluff-free cloth.
Do not use any cleaning agents or solvents.
Disposal
In order to dispose of your device, take it to a collection point
provided by your local public waste authorities (e.g.recycling
centre).Accordingtothelawsonthedisposalofelectronicand
electricaldevices,ownersareobligedtodisposeofoldelectronicand
electricaldevicesinaseparatewastecontainer.Theadjacentsymbol
indicates that the device must not be disposed of in normal domestic
waste!
Youarelegallyobligedtodisposeofpowerpacksandbatteries
atthepoint ofsaleorinthecorrespondingcontainersprovided
at collection points by local public waste authorities. Disposal
is free of charge. T he symbolsindicate thatthe batteriesmust
notbedisposedofinnormaldomesticwasteandthattheymust
be brought to collection points provided by local public waste
authorities.
Packaging materials mustbe disposed ofaccordingtolocal regula-
tions.
Guarantee
SWITELequipmentis produced and tested according tothe latest
production methods. The implementation of carefully chosen materi-
als and highly developed technologies ensuretrouble-free function-
ing and a long servicelife.The terms of guarantee do not apply to
the batteries or power packs usedin the products.The period of
guaranteeis 24 monthsfrom the dateof purchase.
All deficienciesrelatedto materialor manufacturing errors within the
period of guarantee will be redressed free ofcharge.Rightsto
claimsunder the terms of guarantee are annulled following tamper-
ing by the purchaseror third parties.Damage caused as theresultof
improperhandling or operation,normal wear and tear, incorrect
positioningor storage,improperconnection or installation or Actsof
God and other external influences are excluded fromtheterms of
guarantee.Inthecase of complaints,we reservethe right to repair
defective parts,replace themor replace theentiredevice.Replaced
partsor devices become our property. Rights to compensationin the
case of damage are excluded where there is no evidence of intent or
grossnegligence by themanufacturer.
Ifyourdevice does show signs of a defectwithin theperiod of guar-
antee,please contactthe salesoutletwhere you purchased the
SWITELdevice,producingthe purchase receipt as evidence. All
claimsunder the terms of guarantee in accordance withthisagree-
mentcan only be asserted atthe sales outlet.No claims under the
terms of guaranteecan be asserted after a period of two yearsfrom
the date of purchase and hand-over of the product.
Declaration of C onformity
This device fulfils the requirements stipulated in the Directive
1999/5/EC on radio equipment and telecommunications ter-
minalequipmentandthemutualrecognitionoftheirconformity.
Conformitywith theabovementioneddirectiveis confirmedbytheCE
mark on the device. To view the complete Declaration ofConformity,
please refer to the free download available on our web site
www.switel.com
.
