12 © SAMSUNG Electronics Co., Ltd.
Functions of Each Part
Button Functions
,
Select Buttons This button is used to select a desired function from the
menus displayed on the LCD screen.
LCD Screen LCD screen is composed of
the status and main screens.
- The setup status of the
telephone function is
displayed on the upper part
of the LCD screen as icons.
- The LCD main screen, except the status screen, displays
the menus, call process status, or various messages.
Status Light The red LED displays the telephone status such as busy,
ringing and receiving internal message.
Screen Button This button is used to select the screens of AOM, Soft
menu, or background.
Volume Button This button is used to adjust the volume of handset,
speaker, or key tone.
Scroll Key This button performs the same function as [ ][ ] of
Navigation when selecting functions. You can see the
menus or contents of the next page that is not displayed
on the current screen by scrolling the key up and down
Conference Button This button is used to make a conference call.
Transfer Button This button is used when transferring a busy call,
or setting functions in the button on the AOM screen.
Navigation Button This button is used to operate Phonebook, E-diary,
Message, Sound/Screen, or Conference function.
Microphone You can speak via the microphone when making a
conversation with speakerphone.
Hold Button This button is used to hold a call.
Speaker Button
This button is used to call via the speakerphone, not use
the headset.
Dial Button This button is used to enter numbers and characters.
Speaker You can hear caller’s voice or various incoming rings via
the speaker.
