1 2
Specification
Model
Case Type
Dimension
(H*W*D)
Net Weight
Side Panel
Color
Material
Cooling System
Drive Bays
-Accessible
-Hidden
-HDD Docking
Expansion Slots
Motherboards
I/O Ports
PSU
LCS Upgradable
Other
VM400M1W2Z VM400M1W2Z-B
Mid Tower
490 x 215 x 480 mm
(19.3 x 8.5 x 18.9 inch)
6.85 kg / 15.10 lb
Window
Exterior & Interior : Black
SECC
Front (intake) :
120 x 120 x 25 mm Blue LED fan
(1000rpm,16dBA,for VM400M1W2Z only );
120 x 120 x 25 mm Red LED fan
(1300rpm,17dBA,for VM400M1W2Z-B only); or
140 x 140 x 25 mm fan x 1 (optional)
Rear (exhaust) :
120 x120 x 25 mm Turbo fan (1300rpm,17dBA)
Top (exhaust) :
230 x 230 x 20 mm silent fan (800rpm,15dBA)
10
3 x 5.25’’, 2 x 3.5’’
5 x 3.5’’
2.5” & 3.5’’ x 2
7
9.6” x 9.6” (Micro ATX), 12” x 9.6” (ATX)
USB 3.0 x 1, USB 2.0 x 1, HD Audio x 1
Standard PS2 PSU
Supports 1/2”, 3/8”, 1/4” water tube
CPU cooler height limitation: 165mm
VGA length limitation: 315mm
Figure
Parts Name
6#32 stand off
Q'ty
Used for
5
Motherboard
M3 screw
17
FDD & FDD Motherboard
6#32 hexagon screw
5
HDD Power PCI bracket
6#32 screw
5
HDD Power PCI bracket
2
Arrange Wire
6#32 screw
2
Power
Cable tie
1
PowerPower holder
Accessory
Chapter 1. Product Introduction
Chapter 2. Installation Guide
Chapter 3. Leads Installation Guide
Case LED Connection
USB 2.0 Connection
USB 3.0 Connection
Audio Connection
2.1
2.2
2.3
2.4
2.5
2.6
2.7
2.8
2.9
1.1
1.2
1.3
3.1
3.2
3.3
3.4
02
02
03
05
06
07
09
10
12
18
19
20
21-27
21-27
21-27
21-27
Contents
Specification
Accessory
Warning and Notice
Side Panels Disassembly
Motherboard Installation
5.25" Drives Installation
Chapter 4. Other
Toughpower/ Purepower/
TR2 power supply series (optional)
4.0
28
3.5" Drives Installation
3.5" HDD Installation
Top HDD Docking
PSU Installation
PCI Card Installation
Front Fan Installation (optional)
