Philips SCD530 [12/256] Menu operation general explanation

Note: If you do not press the lullaby button K for more than 2 seconds, the lullaby shown on the display

starts to play.

The number of the lullaby appears on the display together with the lullaby symbol K.

The lullaby repeats continuously.

3 To stop the lullaby, press the play/stop button E on the baby unit again. (Fig. 27)

The number of the lullaby and the lullaby symbol K disappear from the display.

4 To select another lullaby when a lullaby is playing:

Press the lullaby button K on the baby unit within 2 seconds to toggle through the list of

lullabies.

Note: If you do not press the lullaby button K for more than 2 seconds, the lullaby shown on the display

starts to play.

Humidity

When there is a connection between the baby unit and the parent unit, the humidity level is shown

on the display of both units.

The optimal humidity level is between 40% and 60%. It is very important to maintain the correct

humidity level as it helps to protect your baby from irritation of the mucous membranes, dry and

itchy skin, chapped lips and a dry, sore throat. When the mucous membranes do not function

optimally, they cannot give your baby full protection from all kinds of germs. This increases the

chance of your baby catching a cold or the u, and reduces its resistance to infections from mould

and bacteria.

The Philips AVENT Ultrasonic Humidier can help you improve the air quality and maintain a

comfortable humidity level in your baby’s room. Contact your local Philips Consumer Care Centre

for stockists.

Note: The baby monitor only measures the humidity level. You cannot adjust the humidity level with the

baby monitor.

Out of range alert

When the parent unit is out of range of the baby unit, the parent unit beeps from time to time and

the message ‘Not linked’ appears on the display. The LINK light on the parent unit lights up red.

Note: The message ‘Not Linked’ also appears on the display of the parent unit when the baby unit is

switched off.

Menu options

Most functions can be operated on both the baby unit and the parent unit, but some functions can

only be operated in the menu of the parent unit.

Menu operation - general explanation

Note: Menu functions can only be operated when a connection has been established between the baby

unit and the parent unit.

1 Press the MENU button to open the menu (Fig. 29).

The rst menu option appears on the display.

2 Use the – and + buttons to select the desired menu option (Fig. 30).

Note: The arrow indicates in which direction you can navigate.

3 Press the OK button to conrm (Fig. 31).

4 Use the + and - buttons to select the desired setting.

5 Press the OK button to conrm.

ENGLISH12
