Soundmax SM-SA602 [14/27] Specification

SOUNDMAX SM-SA602

Specification

MODEL

SM-SA602

Stereo /Bridged

Nominal output power (DIN 45 342, B+=14. 4V) 2 x 60W /1 x 120W at 4 0hms

Nominal output power (DIN 45 342, B+=14. 4V) 2 x 120W at 2 0hms

OPERATION INTO 4 OHMS @ 1KHz, 1% THD 250 W  1

Loudspeaker impedance (stereo) 2-8 Ohms

Frequency response 20 - 60 000 Hz (-3 dB)

Total harmonic distortion <0.05% (1 kHz)

Stereo separation >80 dB (1 kHz)

Signal to Noise Ratio >95 dB

Input sensitivity LOW LEVEL INPUT 0.2-5V

Input impedance LOW LEVEL INPUT 47 KOhms

Low-pass filter 40-350 Hz, 12 dB per octave

High-pass filter 80-2500 Hz, 12 dB per octave

Bass boost 0. . . 12 dB at 45 Hz

Power supply +12V (9-15V), Negative Ground

Fuse rating 25A

Dimensions: WxHxL 270 x 52 x 210 mm

Weight 3. 15 Kgs

NOTE : Specifications & design subject to change without notice for improvement

The pictures have been done for reference and can be different from real units.
